1.   Keep the oil in tank clean, avoid damagingits accessories.

2.   Open the cooling water device beforebeginning working, to avoid its temperature being too high.

3.   Add the 68# hydraulic oil until oil gaugereach to 80%.

4.   Start MORTOR, press UP and DOWN buttons 5-6times, and then press the AUTO button.

5.   Adjust the cylinder HIGH-LOW button to setthe cutting speed and time according to the height of shoe moulds.

6.   Set a specific figure for number of units,and then press the AUTO button.

7.   If found the rubber cut being long or shortunequally.

A. Check whether the transmitting gear ofdecoder work nomally, whether gear space is too big.

B. Check if the springs at two sides of rollerare too loose.

C. Check whether the transmission chain tooloose.

D. When feeding, the rubber must be throughevery gap bridge rollers.

E.  Adjust feeding pressure valve &throttling valve.

F.   If found any stop-feeding phenomenon, solveit according above 7(D). Feeding must be put into in the same level.

8.   If found the rubber could not be cut.

A. Adjust cooling water to right temperature,adjust pressure valve.

B. Adjust to elongate the cutting time.

9.   The highest pressure in using is100kg/cm about hydraulic oil, the nomalone being 50-70kg.

10. Piston & cylinder linner must be keeplubrication by adding oil once a week (when bubble appears)

11. Little fault under normal use, it isordinary because fuse burned, panel damaged electromagnetic coil damaged, orpowder attaches to transducer.
