感謝您購買RD31高清數字防水錄像機。本產品具有超小、精致、人性化防水設計的特點。配合多功能支架使用，可讓您在戶外各種條件下，實現全角度的錄像/監控。

Thank you for purchasing RD31, Waterproof HD Digital video camera. This product is quite small and delicate with wonderful waterproof humanity design. With a multipurpose stand, it can help youachieve omni-directional video / monitoring under all kinds of outdoor conditions.

200萬COMS+運動防水+夜間拍攝+72度視角+手動攝像/拍照+PC攝像頭+邦帶+支持16GB TF卡+可替換式哩電池,視頻時間顯示，640*480 30幀，AVI視頻格式， 尺寸：82.6mm*42.7mm*34.7mm

> Unique water-proof feature, be able to work under water 30 meters

獨特的防水特點，能滿足水下達30米的工作需求

> 2.0 megapixels camera lens, low illumination, strong LED light

兩百萬像素高清鏡頭，擁有良好低照度性能,高亮LED燈照明

> Excellent video recording and photo-taking effect

**的拍照和攝像功能

> Video: 640 x 480 px, 30 frames/sec,AVI; Photo: 1600*1200dpi, JPG

錄影：640 x 480 px，30幀，AVI；照相：1600*1200dpi, JPG

> Replaceable rechargeable long lifespan lithium battery

續航能力強，可更換，可充電的鋰電池

> Support up to 16 GB micro SD(TF) card

**大支持16GB SD卡

> Continuous video recording time reaches 2 hours

**低2小時持續影響錄制

> With Mini USB port, upload and download datas via PC quickly and freely

迷你USB接頭，自由高速傳輸數據

> Easy to install and use on various occasions: cycling, motor racing, hiking, exploring，skiing and many kinds of underwater activities, etc

適合各種環境安裝使用：自行車運動**賽，遠足，探險，滑雪以及各種水下運動等等

參數

Parameters

鏡頭                     200萬CMOS鏡頭

Camera lens         2.0 Mega pixels CMOS lens

分辨率                  640*480 VGA

Resolution           640 * 480 VGA

幀數                     30幀/秒

frame numbers   30 frames / sec

視角                 72度

Angle of view              72 degrees

照片格式            JPEG 1600 * 1200

Photo format        JPEG 1600 * 1200

**小照度              1 LUX

Minimum illumination 1 LUX

電池容量              200 MAH

Battery capacity    200 MAH

持續錄像時間      70分鐘（不開LED）

Continuous video recording time            70 minutes（With no LED light on）

功耗                 150MA/3。7V（**大）

Power consumption    150MA / 3. 7V (max.)

儲藏溫度              -10C-70C

Storage Temperature         -10C-70C

操作溫度              -30C-60C

Operating Temperature      -10C-60C

操作濕度              15-85%RH

Operating Humidity            15-85% RH

防水深度          3M

Waterproof depth   3m

記憶卡類型           Micro SD卡（TF卡）

Type of memory card         Micro SD card (TF card)

記憶卡容量          **大可以支持16GB

Capacity of memory card          can support up to 16GB (max.)

USB接口             USB 1. 1 / 2. 0

USB Interface      USB 1. 1 / 2. 0

操作系統              2000/XP/VISTA 32

Operating system        2000/XP/VISTA 32

充電時間              2小時左右

Charge period      about two hours
